Description
*COME WITH MANUAL BOOK, NO BOX. GOOD CONDITION.
DESIGN :
4-driver, 3-way center channel
CROSSOVER :
2nd-order electro-acoustic at 2.1 kHz; 2nd-order electro-acoustic at 500 Hz (bass drivers)
HIGH FREQUENCY DRIVER :
25-mm (1 in) G-PAL™ dome, ferro-fluid damped / cooled, die-cast heatsink chassis, IMS/SHOCK-MOUNT™
FREQUENCY RESPONSE ON-AXIS :
±2dB from 65 Hz – 20 kHz
FREQUENCY RESPONSE :
30° OFF-AXIS±2dB from 65 Hz – 18 kHz
MIDRANGE FREQUENCY DRIVER89-mm (3-1/2 in) S-PAL™ cone, ferro-fluid damped / cooled, 25-mm (1 in) voice-coil, AVS™ die-cast heatsink chassis, IMS/SHOCK-MOUNT™
LOW FREQUENCY DRIVERTwo 140-mm (5-1/2 in) mineral-filled polypropylene cones, 38-mm (1-1/2 in) voice-coils, AVS™ die-cast heatsink chassis, IMS/SHOCK-MOUNT™
SENSITIVITY ROOM / ANECHOIC: 90 dB / 87 dB
LOW FREQUENCY EXTENSION: 43 Hz (DIN)
SUITABLE AMPLIFIER POWER RANGE: 15 – 220 watts
MAXIMUM INPUT POWER: 150 watts
IMPEDANCECompatible with: 8 ohms
DIMENSIONS HXWXD: 8.375″ × 19.25″ × 11.375″ (21.3cm × 48.9cm × 28.9cm)
WEIGHT: 27 lbs. (12.2 kg)
https://www.cmy.com.my/shop-online/paradigm-studio-cc-490-v-5center-speaker/
For more information:
Contact : Dicky Ng 012-3308893
Contact : John Yew 016-2861000
Email : dickyng@cmy.com.my
Or visit our showroom:
CMY Audio & Visual
F007 - F015, First Floor, Sungei Wang Plaza, Jalan Sultan Ismail, 50250 Kuala Lumpur
The item represented is being sold by a Commercial Member. This means they have certain legal requirements when selling new and second-hand goods, and must provide a statuatory warranty under Consumer Law applicable to their location. These requirements may differ depending on their region, so discuss these entitlements with the Seller prior to purchase.
