SPECS
Device type: Digital signal processor/digital-to-analog converter/digital preamp
Connections: Two RCA inputs,two XLR inputs, two RCA outputs, two XLR outputs, one TosLink S/PDIF digital input, one TosLink S/PDIF digital output
Digital processing: 40-bit, 2-channels
ADC: 6.144MHz oversampling dual per channel
DAC: 6.144MHz oversampling dual per channel, local clocking, buffering
Dynamic range: > 108dB
Volume control steps: 0.5dB
Input sensitivity: XLR, 1.35/2.60V RMS; RCA, 1.65/3.25V RMS
Output voltage: RCA, 1.65V RMS; XLR, 3.25V RMS
Dimensions: 236 x 55 x 146mm
The item being advertised is sold "as is", and no warranty should be assumed unless otherwise indicated and agreed between the Buyer and the Seller. Photos representing the item being advertised form part of the description unless otherwise specified.
